精度precision

C

2

型号Model

J

J88

量程Range

kg

0.5~25

灵敏度Rated Output

mv/v

1.0/2.0±0.15

非线性Non-linearity

%F.S

0.05

滞后 Hysteresis

%F.S

0.05

重复性Repeatability

%F.S

0.05

蠕变Creep

%F.S/3min

0.05

温度零点Temp.effect on zero

%F.S/10℃

0.05

温度灵敏度Temp.effect on span

%F.S/10℃

0.05

零点输出Zero balance

mv/v

±0.05

输入阻抗Input impedance

Ω

405±10

输出阻抗Output impedance

Ω

350±5

绝缘电阻Insulation resistance

MΩ

≥5000（50VDC)

推荐激励电压Recommended excitation voltage

VDC

3~10

温度补偿范围Compensated temp.Range

℃

-10℃~+40℃

工作温度范围Operating temp.Range

℃

-20℃~+60℃

安全过载Safe overload

%F.S

120

极限过载Ultimate Overload

%F.S

150

接线方法Connection

Excitation:    Red: E+    Black:E -

Signal:        Green:S+   White:S-
